Freestanding Quad Monitor Support for Total Immersion
The Trak Racer Freestanding Quad Monitor Stand with Extra Leg Supports is a professional solution for mounting 4 monitors or TVs in advanced racing simulator, sim racing, and flight simulation setups. Its configuration allows for a main triple screen setup of up to 50" and a fourth upper monitor of up to 45", ideal for telemetry, maps, rearview mirrors, race information, or auxiliary panels.
Designed as a freestanding floor stand, it does not need to be directly attached to the cockpit, which allows for more precise, stable placement adaptable to different driving positions. Its 80 x 40 mm extruded aluminum structure offers a solid, rigid base prepared for demanding configurations.
Key Advantages for Quad Screen Setups
-
Freestanding support for 4 monitors, ideal for high-level immersive configurations.
-
Main triple screen up to 50" and upper monitor from 16" to 45".
-
Reinforced structure with additional leg supports, designed to improve stability.
-
80 x 40 mm extruded aluminum construction, robust, durable, and resistant to flexing.
-
Height, width, depth, and angle adjustment, to adapt each screen to your driving position.
-
Up to 90 degrees of rotation, perfect for setting the angle of the side monitors.
-
VESA mounts included, compatible with most common standards.
-
Universal One Size Fits All design, compatible with most screens within the indicated measurements.
- Product from Trak Racer, official simulator provider for Alpine F1 Team and Airbus Aircraft partner.
-
Lifetime warranty under conditions of correct assembly and appropriate residential use.
Key Features of the Trak Racer Freestanding Quad Monitor Stand
-
Product: freestanding quad monitor stand
-
Model: MS-FM-QD2-FM-EU
-
Installation type: freestanding / floor mount
-
Number of screens: up to 4 monitors or TVs
-
Main configuration: triple monitor up to 50"
-
Upper monitor: compatible with screens from 16" to 45"
-
Material: high-strength extruded aluminum
-
Structural profile: 80 mm x 40 mm
-
Arms included: additional triple monitor arms 880 mm / 34.65"
-
Available adjustments: height, width, front/back position, angle, and rotation
-
Maximum rotation: up to 90 degrees
-
VESA compatibility: 75 / 100 / 150 / 200 / 300 / 400 mm
-
Indicated maximum capacity: up to 170 kg depending on appropriate configuration
-
Warranty: Lifetime
Complete Visual Control for Sim Racing and Flight Simulation
A quad-screen setup allows you to go beyond panoramic vision. While the three main screens offer an immersive view of the track or cockpit, the upper monitor adds an extra layer of useful information without saturating the main view.
In sim racing, this configuration can be used to display telemetry, lap times, race management, or external dashboards. In flight simulation, it is especially useful for instruments, maps, navigation, or auxiliary data. The result is a more organized, immersive, and professional-like experience.
Compatibility and Installation Requirements
The Trak Racer Freestanding Quad Monitor Stand is designed to be installed on a flat surface and to mount a setup of up to 4 screens.
Screen compatibility:
- Up to 3 monitors or 50" TVs in a triple configuration.
- Upper monitor compatible with screens from 16" to 45".
- Compatible with most VESA-mounted monitors and TVs.
- Final compatibility depends on the rear mounting points of each screen.
- Does not include monitors, electronics, or cockpit.
VESA compatibility included:
- 75 x 75 mm
- 100 x 100 mm
- 150 x 150 mm
- 200 x 200 mm
- 300 x 300 mm
- 400 x 400 mm
Technical Specifications
| Feature |
Detail |
| Brand |
Trak Racer |
| Model |
MS-FM-QD2-FM-EU |
| Product |
Freestanding quad monitor stand |
| Support type |
Freestanding / floor |
| Number of screens |
Up to 4 |
| Max triple monitor size |
Up to 50" per screen |
| Upper monitor size |
16" to 45" |
| Material |
Extruded aluminum |
| Structural profile |
80 mm x 40 mm |
| Arms included |
880 mm / 34.65" |
| Height adjustment |
Yes |
| Width adjustment |
Yes |
| Front/back adjustment |
Yes |
| Angle adjustment |
Yes |
| Maximum rotation |
Up to 90 degrees |
| VESA compatibility |
75 / 100 / 150 / 200 / 300 / 400 mm |
| Indicated maximum capacity |
Up to 170 kg |
| Warranty |
Lifetime |
Included Content
| Quantity |
Item |
| 1 |
Trak Racer Freestanding Single Monitor Stand |
| 1 |
Set of VESA mounting plates |
| 1 |
Upper fourth monitor mount |
| 1 |
Set of additional triple monitor arms 880 mm / 34.65" |
| 1 |
Kit of necessary screws and fixings |
Expand Your Setup with a Professional Visual Configuration
A robust, adjustable solution prepared for those seeking the highest level of immersion. The Trak Racer freestanding quad monitor stand allows you to create a complete, stable, and precise visual environment for sim racing, flight simulation, and advanced high-performance setups.
